ST2018L 20MM Ball Linear Stepper-Nema8
Very small high-torque stepper motor in size NEMA 8 (20 mm) with 1.8° step angle (full step), high torque and speeds of up to 3000 rpm. Available in three lengths. An extensive range of customized shaft and cable versions as well as custom-made products can be found under Custom solutions.
Features
- This motor can be combined with a gearbox of the GPLL22 series or the GPLE22 series.
- The version with B shaft can also be ordered with an NOE1 encoder (optional).
Specifications
| Size(mm): | 20 mm |
| Resolution (um): | 1.8 um |
| Rated Speed (RPM): | 600 rpm |
| Torque (Nm): | 0.036 Nm |
| Resolution (um): | 1.8 |
| Integrated Encoder: | No |
| Optional: | Encoder & Gearbox |
| Controllers / Drives Optional: |
CL3-E – Motor controller for CANopen, Modbus RTU or USB |
Dimensions
Torque Curves
Related Files
| File | Type | Size | Last update | Link |
|---|---|---|---|---|
| ST2018L0804-A 3D Model | stp | 200.513KB | December / 17 / 2019 | Download |
| ST2018L0804-A Data Sheet | 94.108KB | December / 17 / 2019 | Download | |
| ST2018L0804-B 3D Model | stp | 238.494KB | December / 17 / 2019 | Download |
| ST2018L0804-B Data Sheet | 103.348KB | December / 17 / 2019 | Download |
