ST4209L 42MM Ball Linear Stepper-Nema17
High-torque stepper motor in size NEMA 17 (42 mm) with 0.9° step angle (full step). Ideal for applications in which a higher resolution is to be achieved in openloop mode without encoder. Available in various lengths and versions. An extensive range of customized shaft and cable versions as well as custom-made products can be found under Custom solutions.
Features
- This motor can be combined with a gearbox.
- The version with B shaft can also be ordered with an encoder (optional).
Specifications
| Size(mm): | 42 mm |
| Resolution (um): | 0.9 um |
| Rated Speed (RPM): | 600 rpm |
| Torque (Nm): | 0.44 Nm |
| Resolution (um): | 0.9 |
| Integrated Encoder: | No |
| Optional: | Encoder & Gearbox |
| Controllers / Drives Optional: |
CL3-E – Motor controller for CANopen, Modbus RTU or USB |
Dimensions
Torque Curves
Related Files
| File | Type | Size | Last update | Link |
|---|---|---|---|---|
| ST4209L1206-A 3D Model | stp | 933.179KB | December / 19 / 2019 | Download |
| ST4209L1206-A Data Sheet | 106.159KB | December / 19 / 2019 | Download | |
| ST4209L1206-B Data Sheet | 107.4KB | December / 19 / 2019 | Download | |
| ST4209L1206-B 3D Model | stp | 953.243KB | December / 19 / 2019 | Download |
